High Feed SP07
High Feed SP07 milling system for maximum productivity. Fast material removal with excellent surface quality.Discover our SP07 range
Looking for a tool that keeps up with your day-to-day milling needs? The High Feed SP07 is designed to handle a wide mix of materials and jobs, replacing older tools with something more reliable and easier to work with. Thanks to its positive cutting rake angle, it clears chips efficiently even when running unmanned productions.
Flexibility and dependability across the board
The High Feed SP07 is a flexible and dependable milling tool that pushes productivity levels across lots of different materials and applications.
From side milling to slotting and pocketing to plunging. Whether you’re milling steel, stainless, or superalloys, this tool is the best solution for getting the most out of your machines.
Your Challenge
Switching tools for different materials and machining strategies can lead to unpredictable results, faster wear and higher costs. With ‘regular’ tools you will need higher power or rigidity to get the highest performance.
Our Solution
High Feed SP07 replaces outdated tools with one reliable solution. It’s easy to use, reduces your tool inventory and helps you run efficient, unmanned production with reliable chip evacuation, particularly on complex components.
Keep your productivity on track
Each insert has four cutting edges, so you get more use out of each one. The stable insert design and constant lead angle give predictable cutting behavior, and the high metal removal rates, even with a depth of cut as shallow as ≤0.8 mm (0.03”), mean you won’t be slowed down.
Combined, these factors will undoubtably help you stay on track with your productivity targets.
Your Challenge
Pressure to reduce cost per part is constant, and traditional tools often wear out quickly and require frequent replacement in difficult applications, driving up your expenses.
Our Solution
With four cutting edges per insert, High Feed SP07 gives you a longer tool life and a better price-to-performance ratio without slowing you down.
Easy handling and predictable behavior
Digital traceability via the Data Matrix codes mean you spend less time searching through catalogs and swapping tools and more time getting the job done.
The system is simple enough to manage even with limited skilled labor.
Your Challenge
A shortage of skilled employees and reduced tool management resources make complex tooling systems impractical and increase the risk of errors.
Our Solution
The High Feed SP07 is straightforward to use and easy to track, making it ideal for high volume or unmanned production.
Technical specifications
| Diameter range: | 20-40 mm (0.75”- 1.50”) |
| Spanning: | From 20 to 40 mm (0.75" to 1.25") |
| Depth of cut: | 0,8 mm (0.031”) to 0,65 mm (0.026") |
| Shank type: | Arbor, Combimaster and Cylindrical |
| Pitch option: | Normal and Close |
| Number of items: | 29 cutters and 12 inserts |
| Applications: | Slotting, side, plunge, pocketing, helical interpolation, face. |
| Material: | P, M, K, S, H |
Material suitability
Cutter pitch availability
Metric
| Diameter |
| 20 | 25 | 32 | 35 | 40 |
| No. of teeth | Arbor | - | - | - | - | 6 |
| Combimaster | 2-3 | 3-4 | 4-5 | 5 | 5-6 |
| Cylindrical | 2-3 | 3-4 | 4-5 | 5 | - |
Inch
| Diameter |
| 0.75" | 0.79” | 1.00” | 1.25” | 1.26” | 1.38” | 1.50” |
| No. of teeth | Arbor | - | - | - | - | - | - | - |
| Combimaster | 2 | - | 3-4 | 4 | - | - | 5 |
| Cylindrical | 2 | 3 | 3-4 | - | 5 | 5 | - |
Tool life vs competition
A test was conducted against 4 competitors in titanium 6-4.
The image marked with blue shows the results and tool wear after using the High Feed SP07 compared to the other brands while the graph shows the wear rate.
